Maritime Equipments
JMA-1030 Radar
NON-SOLAS CAT3 <500GT
- AIS and MARPA+ as standard
- Proprietary System-on-Chip technology
- High performance scanners
- Simple and intuitive operation
Description
The new JMA-1030 radar series is JRC’s very first touch operated radar with new dome scanners that provide you with highly accurate target clarity and ease of mind of your surroundings during night or intense fog.
The high definition 7-inch wide display has allowed JRC engineers to develop an exciting new software approach that offers an incredibly easy-to-use icon based navigation experience with simple menus and dedicated functions. The set of icons has been carefully designed. We brought the elements and visual style of our commercial class Multi Function Display (MFD) to our most compact series of radars. Built with the proven quality you expect from us. JRC engineers custom designed the System-on-Chip (SoC) inside the new JMA-1030 series to be an extremely powerful tool and at the same time makes the display compact and very power efficient. The new radar has the ability to display 50 AIS1 symbols, and 10 MARPA™2 tracking targets as standard.
JLR-21 GPS Satellite Compass
GPS Satellite Compass
Description
The JLR-21 GPS compass continues the success of its predecessor, reaching a new level of performance and stability with many new features and enhancements. This system is also known as a 3D Dynamic Sensor™, which besides giving heading information, is designed to provide highly accurate information of the ships movement in all axis.
The JLR-21 has heave functionality built-in as standard. In rough ocean conditions (with high waves), the GPS compass can correct up and down (attitude), movement. JLR-21 supports Speed Over Ground (SOG) and Course Over Ground (COG). The position, SOG and COG are updated every 200 milliseconds (which is 5 times faster than previous model JLR-20), delivering high accuracy.
JLR-4341
DGPS Sensor
- Internal Differential Beacon Receiver
- Capable of SBAS (WAAS/EGNOS/MSAS) correction
- RAIM function is available
- 12-Channel Parallel for simultaneous reception of 12 satellites
Description
-
The sophisticated “all-in-view” JLR-4341 DGPS receiver uses up to 12 satellite signals to pinpoint your exact location. The JRC DGPS receiver integrates GPS measurement via correction data transmitted from the SBAS satellites (WAAS, EGNOS, MSAS) and by using the internal differential beacon receiver you can achieve true DGPS accuracy. RAIM functionality is included to assess the integrity of GPS signals in the DGPS receiver, assuring higher reliability in global positioning than conventional methods. The NMEA0183 output can be configured as version 1.5, 2.1 or 2.3, thus allowing connection with various types of marine equipment including radars, fish finders and plotters.
The base of the DGPS receiver is designed for easy installation, either on to a navigation antenna mount unit or on an extension mast. The antenna base includes a slot allowing for easy cable management, significantly reducing installation time. You can link power supplied by connected (D)GPS navigation equipment, directly to the DGPS receiver.
JFE-380
Echo sounder
- 6.5-inch high visibility color TFT display
- Highly accurate and reliable read-out
- Range 10, 20, 50, 100, 200, 500, 800m
- 24 hours of depth data memorizing
Description
The JFE-380 echo sounder continues the tradition of enhanced depth data technology resulting in highly accurate and reliable read-out functionality. JRC’s enhanced depth data technology has three central presentation modes, i.e. standard, history and docking. Both standard and docking mode provides a wide range of information. This is stored in the memory for up to 24 hours. The history mode allows you to retrieve all memorized depth data to provide complete feedback.
JRC’s new echo sounder incorporates a 6.5-inch high visibility color TFT display. The innovative display modes allow you to select and view echoes in 8 colors or 8 levels of monochrome. Additionally, the size-reduced JFE-380 echo sounder incorporates printer adaptability, providing the ship’s log with valuable printouts if required. The compact connection box can be installed out of sight. An optional dual frequency configuration, 50 kHz and 200 kHz, allows you to operate both frequencies independently or simultaneously, or allows you to have a separate bow-stern depth read-out.
FF-901
Chartplotter/Fishfinder
Description
-
A multifunctional marine system designed to put every detail at your fingertips. Complete with 9-inch touch display the FF-901 offers an easy to operate solution for navigating and fish finding. The system can be operated in multiple ways. The FF-901 maximizes the benefits of the touch screen with the reliability of an ergonomic keyboard. The rotary knob gives you a fast and precise control in every condition, while the touch screen allows the best experience in map exploration and route building. The system offers user customizable keys. Programming F keys give you instant access to three of your favorite functions.
As the FF-901 is C-Map 4D and Max compatible, you will experience the latest evolution of electronic charting technology and the ability to view charts in 2D or amazing 3D presentation with high-resolution satellite imagery. Try the Easy Routing and the Route Check to improve your routes.
What about duplicating your plotter on your tablet? It’s easy: establishing a Wi-Fi connection, you can use your tablet as a touchscreen chart plotter! Software updates come easy. Keep your chart plotter always up to date, thanks to the Wi-Fi connectivity. Synchronize your data with cloud connectivity and manage routes, tracks and marks from any connected device. Build your favorite routes easily at home, and find them ready on your chartplotter.
NBF-3 NMEA 0183 Buffer NMEA
- Safely drive up to six NMEA Listeners, with power distribution for the connected Talker
- NMEA 0183 outputs compatible with RS422, RS232 and RS485 type Listeners
- NMEA 0183 input compatible with RS422 and RS232 type Talkers
- Power and input indicator LEDs
Description
-
The Actisense NBF-3 NMEA Buffer isolates and buffers NMEA 0183 data, with the power to drive multiple devices.
The NBF-3 can distribute up to six identical, amplified streams of data from one source. The NMEA signals are buffered to ensure that each Listener receives the data at the required voltage levels, providing consistent data quality.
The isolation on the input and each of the outputs ensures the protection of the source Talker device and all the Listening devices. The safe connections mean that a non-isolated device could be connected and the NBF-3 would prevent it from causing any damage to the other equipment in the system. Ground loops often occur when devices are not isolated and can cause irreparable damage. Actisense ISO-Drive technology on the outputs along with the galvanic opto-isolation on the input means you can connect the NBF-3 with complete peace of mind.
The NBF-3 has the addition of power distribution for the NMEA Talker. By having power and data from the same source, cabling requirements are reduced and installation is simple.
Features
• Galvanic opto-isolation on the NMEA 0183 input
• ISO-Drive™ NMEA 0183 outputs provide galvanic isolation to prevent ground loops
• Compatible with all NMEA 0183 versions without requiring configuration
• NMEA 0183 outputs compatible with RS422, RS232 and RS485 type Listeners
• NMEA 0183 input compatible with RS422 and RS232 type Talkers
• DIN Rail mountable
• Pluggable screw terminals for quick and easy installation and diagnostics
• Power and input indicator LEDs
• Works automatically up to 115200 Baud
• Amplification of weak input signals
• Power feed for single cable installation to the NMEA Talke
Cobham SATCOM SAILOR 4300 L-band: Iridium Certus
Built for Iridium Certus℠, the new SAILOR 4300 L-band leverages decades of L-band expertise to deliver dependable connectivity with higher performance, low costs and truly global coverage.
Description
SAILOR 4300 L-band is the first in Cobham’s Iridium Certus℠ Connected range of terminals. It is the perfect choice as either a high-performance, stand-alone terminal to upgrade your vessel communications, or as a dependable backup solution for your existing VSAT system.SAILOR 4300 L-band is the first in Cobham’s Iridium Certus℠ Connected range of terminals. It is the perfect choice as either a high-performance, stand-alone terminal to upgrade your vessel communications, or as a dependable backup solution for your existing VSAT system.Through Iridium NEXT, SAILOR 4300 L-band enables fast internet speeds suitable for both data-heavy applications and everyday usage. The terminal minimises total cost of ownership with low hardware costs and no scheduled service requirements, and is fully supported through Cobham SATCOM’s Global Service Network.
⦁ SAILOR quality
⦁ Multiple satellite tracking with no moving parts
⦁ Easy configuration via web and built-in API for 3rd party integration
⦁ Single cable (ADU/BDU – 75m coax) for easy installation
⦁ Bulkhead and 19” rackmount configuration 3 voice lines and 352/176 data speeds (upgradeable to 704/176)Antenna Dimensions: 38 cm (dia) x 23 cm (h)Antenna Weight: 7 kg
Intellian V100NX Marine Stabilized Ku-Band VSAT System
The v100nx from Intellian with 3 axis and 1m reflector diameter delivers the high bandwidth Aura Ku-Band VSAT service to the maritime industry.
Description
Marine Stabilized Ku-Band VSAT System
The v100nx from Intellian with 3 axis and 1m reflector diameter delivers the high bandwidth Aura Ku-Band VSAT service to the maritime industry. Aura is available with a broad range of customisable speeds and packages to address the budgets and operational needs of customers across commercial shipping, fishing, offshore and leisure markets.
Key Features and Benefits
- Tried and Tested Hardware; Reliable and robust Ku hardware from Intellian, backed up with an industry leading 3 year parts and 2 year labour warranty from Intellian.
- Flexible and Affordable Payment Options; Option to rent or purchase equipment outright as required.
- Ku-Band Optimized Reflector; High gain, highly efficient reflector ensures best service quality available for Ku-Band configuration.
- Frequency Tuned Radome; The optimised radome design enhances system performance while the low elevation angle (-20°) capability guarantees reliable connection at extremely high latitude.
- Patent Pending Intellian Global PLL LNB; The world’s first Ku-Band LNB module is capable of receiving a full range of operating frequencies from any VSAT satellite around the globe by remotely changing the frequencies of the LNB.
- Auto Beam Switching (ABS) Available; The v100 supports ABS via OpenAMIP protocol of iDirect and the ROSS Open Antenna Management (ROAM) protocol of Comtech.
- Gyro-Free Satellite Search Capability;Intellian’s new generation Gyro-free satellite search function enables the v100 to acquire and lock onto the satellite without requiring a separate input from the ship’s gyrocompass.
- Seamless End to End Solution; The v100 is easy to install, operate, monitor and maintain, supported by the Satcom Global Support and Engineering teams.
SAILOR 900: Ku-Band VSAT Antenna
SAILOR 900 Ku-Band VSAT Antenna from Cobham SATCOM is a powerful, quick and easy-to-deploy stabilised antenna offering the superb build quality and high reliability that customers expect from a SAILOR product.
Description
The SAILOR 900 Ku-Band VSAT, which has been designed by Cobham SATCOM’s most experienced engineers, is the result of extensive market and technology research.
Features
⦁ High performance RF design
⦁ Antenna radome matches in size the ⦁ SAILOR 90 Satellite TV
⦁ Single coax cable between antenna and antenna controller
⦁ Integrates to leading VSAT modem unit
⦁ 4 axis stabilised low-profile design
⦁ Antenna Control Unit (ACU) with multiple LAN and diagnostics ports
⦁ Built-in Test Equipment (BITE)
The SAILOR 900 Ku-Band VSAT complements Cobham SATCOM’s highly successful SAILOR FleetBroadband series and SAILOR Satellite TV systems.
SAILOR FleetBroadband 500: Satellite Broadband
SAILOR FleetBroadband 500 satellite broadband boasts a small footprint, with a diameter of only 60 cm and a weight of just 16 kg. FB 500 delivers amazing speeds of up to 432 kps. SAILOR FB 500 utilises the Inmarsat satellite network.
Description
Combined with an extensive know-how and hands-on experience from land-based satellite broadband solutions, the Cobham SATCOM SAILOR FleetBroadband range offers all mariners a whole new level of maritime satellite communication.
FEATURES
⦁ IP connection for e-mail & internet/intranet access, inc secure VPN
⦁ ISDN
⦁ Voice and data simultaneously
⦁ Small size hardware
Thuraya Atlas IP: Satellite Broadband
Manufactured for Thuraya by Addvalue Innovation, Atlas IP is a dedicated maritime satellite terminal, supporting voice and broadband IP data connectivity.
Thuraya Atlas IP utilises the Thuraya satellite network.
Description
Thuraya Atlas IP is specifically designed to deliver added value to end-users seeking enhanced connectivity and greater operational efficiency on board ships. It provides merchant maritime, fishing, government and leisure users with a purpose-designed, fully-featured maritime satellite terminal that supports voice and broadband IP data connectivity at speeds of up to 444kbps.
Thuraya Atlas IP features improved power efficiency, a smaller form factor and greater versatility than rival maritime broadband products. The terminal features a single cable connection to the stabilized antenna, direct bulkhead mounting and built-in Wi-Fi.
It also includes a range of features designed to support improved communications functionality and enhance shipboard operations. These include port forwarding, which can automatically transfer data from shipboard equipment and devices in support of M2M reporting routines, an English/Chinese web interface, a built-in firewall, continuous GPS output and the ability to limit data sessions by time or volume.
Iridium Pilot
Iridium Pilot is the next generation of maritime broadband voice and data communications, engineered for durability and reliability, Iridium Pilot provides exceptional performance. Powered by the Iridium OpenPort service and backed by an industry leading five-year limited warranty, Iridium Pilot is the ultimate communications solution wherever you may sail.
Description
Description
Iridium Pilot has been designed to provide the best quality product at the best possible value. Operating on the Iridium OpenPort service, it maintains all the benefits of its predecessor but with additional features and functionality.
Iridium Pilot has a Performance Enhancement Proxy (PEP) to provide enhanced protocol for improved data throughput as well as an integrated firewall to help restrict outbound data traffic to keep usage under control.
Iridium Pilot has a built-in firmware notification system, which will alert users when a new version of firmware becomes available. The antenna performance utility provides real-time antenna usage metrics to assist in troubleshooting performance issues.
The Iridium Pilot ADE design has been tested to withstand harsh marine environments, including:-
⦁ Salt spray
⦁ Water jet
⦁ Temperature extremes
KEY FEATURES
⦁ Fully global operation
⦁ Durable
⦁ Solid-state design, no moving parts
⦁ Reliable
⦁ Maintains connectivity in rough seas
⦁ Broadband (bidirectional data speeds up to 134Kbps)
⦁ Three independent voice lines
Iridium Pilot comes with a 5 year manufacturer’s warranty (terms and conditions apply, associated accessories not included).
SAILOR 100: Maritime Satellite TV Antenna
With a SAILOR 100 Satellite TV system and a receiver from one of the world’s leading satellite TV service providers you can get free-to-air or commercially available packages with multiple TV channels.
SAILOR 100 Satellite TV system forms part of Cobham SATCOM’s (formerly Thrane & Thrane) SAILOR product range.
Description
SAILOR satellite 100 TV is based on the renowned SAILOR 900 VSAT platform. Designed and manufactured in house at Cobham SATCOM, it offers the same superior performance and quality users have come to expect from all SAILOR products.
New Features
A number of exciting new features have been introduced through this product, including:A number of exciting new features have been introduced through this product, including:
⦁ Single cabin installation – for a simpler, more cost effective installation
⦁ Multi-polarisation and programmable LNB – for worldwide TV reception
⦁ Advanced rotary joint – unlimited azimuth range, eliminating the need for cable unwrap
⦁ Powerful touch screen terminal – for setup, service and management
Simple Installation
Installation costs are significantly reduced by the use of a singular coax cable for power, data and TV signal – a feature unique to the SAILOR Satellite 100 TV.
Designed with a large service hatch, the SAILOR Satellite 100 TV antenna has easy access for fast and efficient service. The touch screen terminal offers an intuitive user interface, supporting the straightforward installation, set up and daily operation.
SAILOR 6222: VHF DSC Radio
SAILOR 6222 VHF DSC radio from Cobham SATCOM continues the SAILOR tradition of setting new standards for GMDSS VHF design. It is a vital tool for daily operation and has been developed for the harsh maritime environment as part of the innovative SAILOR 6000 Series.
SAILOR 6222 VHF DSC radio forms part of Cobham Satcom’s SAILOR product range.
Description
The SAILOR 6222 VHF DSC radio continues the SAILOR tradition of setting new standards for GMDSS VHF radio design. It is a vital tool for daily operation and has been developed for the harsh maritime environment as part of the innovative SAILOR 6000 Series. It is based on the same foundation of high reliability, ease-of-use and leading-edge functionality that has positioned SAILOR as the top name in maritime VHFs.
SAILOR 6222 VHF radio provides flexibility through straightforward installation, either as part of a GMDSS console or on its own. As a result of improved, high performance and innovative, easy-to-use functionality the radio offers important operational enhancements. It introduces several new hardware and software improvements, including the improved SAILOR Replay functionality.
The highly advanced 3.2” QVA display ensures the information can be read regardless of the light conditions on the bridge – day or night. The text can be displayed as white on black background, and as black on white background, to provide the optimal reading condition in daylight. Red backlight protects the night vision of the user.
FEATURESFEATURES
- Unique SAILOR Replay (240 sec.) of incoming communication
- High quality display – perfect night and day vision
- Powerful 6W loudspeaker
- Intuitive and easy to operate menu structure ⦁ Large tactile buttons and wheelknobs for easy operation
- The popular and reliable SAILOR handset
- ThraneLINK
Beam IsatDock2 MARINE: Satellite Docking Station
Purpose built IP54 rated docking station supporting alert / tracking, RJ11 / POTS connectivity for using standard telephone handsets, PBX integration or standalone use with inbuilt speaker phone and privacy handset.
Description
BEAM IsatDock2 MARINE is an intelligent docking station for the IsatPhone 2 specifically designed for maritime applications. The MARINE dock supports voice services via Bluetooth, RJ11/POTS for corded phones or PBX support, handsfree speakerphone or the privacy handset. The handset is completely enclosed in the docking unit whilst still giving full access and functionality to the user. IsatDock2 MARINE supports tracking and alert functionality for the IsatPhone 2 handset.
Specialised Design:
⦁ New improved USB docking mechanism
⦁ IP54 maritime grade design
⦁ Supports alert & tracking of handset
⦁ External alert input & alert/track on Dock
⦁ Integrated antenna connection
⦁ Inbuilt speaker / mic for hands free
⦁ Wall or desk mounting bracket
⦁ Integrated auto sensing off hook privacy handset
Intelligent POTS/RJ11 Interface
⦁ Supports up to 600m of RJ11 / Cat5 cable
⦁ Supports up to 600m of RJ11 / Cat5 cable
⦁ Dial, ring & busy tones
⦁ Integrate to PBX system
⦁ Support standard corded / cordless phones
⦁ Auto-dial & speed dials available
Buttons On Dock:
⦁ Ringer / in call volume UP / DOWN
⦁ Ringer / in call volume UP / DOWN
⦁ Track button / alert 2 button press
⦁ In call mute
⦁ Speakerphone button
⦁ Status LED with adjustable brightness
Calling Options:Calling Options:
⦁ RJ11 / POTS phone equipment
⦁ Inbuilt privacy handset
⦁ Speakerphone
⦁ Bluetooth via handset
Installation:
⦁ Wall or desk mounting
⦁ 110 / 240V AC or 10 – 32V DC input (plug pack provided)
⦁ External alert I/O
iDirect Evolution X7: Satellite Router
Powerful, next-generation remote supporting DVB-S2/ACM on the outbound and ATDMA and SCPC* on the return, with performance capabilities for the most demanding applications
Description
The X7 Satellite Router is a powerful, next-generation remote featuring a compact, rack-mount design, embedded 8-port switch, a 2nd DVB-S2 demodulator, variant power supply configurations and Web iSite support making it an ideal enterprise class solution.The X7 Satellite Router is a powerful, next-generation remote featuring a compact, rack-mount design, embedded 8-port switch, a 2nd DVB-S2 demodulator, variant power supply configurations and Web iSite support making it an ideal enterprise class solution.
⦁ Star and SCPC Return upstream channels
⦁ Mobility and optional 256-bit AES encryption features
iDirect Evolution X5: Satellite Router
Designed specifically to support business-critical applications, the Evolution X5 is ideally suited for high-performance broadband applications such as enterprise connectivity, cellular backhaul, maritime, secure banking, and other mobile applications.
Description
The Evolution X5 features iDirect’s highly efficient implementation of the DVB-S2 standard with Adaptive Coding and Modulation (ACM) on the outbound carrier. Along with deterministic MF-TDMA technology or SCPC Return, 2D 16-State FEC, the Evolution X5 maximizes the efficiency of satellite capacity to enable new opportunities.
Features:
⦁ Star topology
⦁ Two modes of operation: iFINITI or DVB-S2/ACM outbound
⦁ Deterministic MF-TDMA or SCPC Return channel
⦁ Extremely efficient 2D 16-state inbound coding
⦁ Advanced QoS and traffic prioritisation
⦁ Automatic end-to-end Uplink Power Control
⦁ Optional Spread Spectrum waveform technology supports very small antennas
SAILOR 6120 mini-C SSAS: Satellite Terminal
The Cobham SATCOM SAILOR 6120 mini-C SSAS is a single, self-contained and sealed terminal, housing both antenna and transceiver.
SAILOR 6120 mini-C SSAS utilises the Inmarsat satellite network.
Description
The Cobham SATCOM SAILOR 6120 mini-C SSAS builds on the successful legacy of the SAILOR TT-3000SSA System, which since its introduction in 2004 has proven its worth in real world incidents, time and time again.
Like its predecessor, the SAILOR 6120 mini-C SSAS is based around a self-contained and sealed Inmarsat mini-C terminal, housing both antenna and transceiver. This design approach has proven to be rugged and reliable regardless of vessel type and with the terminal’s 50 channel GPS module and omni-directional antenna, satellite fix and position are ensured even under the most adverse conditions. The multiple address functionality enables additional message to be sent directly to, e.g. the vessel owner, operator or crew family, in addition to the required flag state and ship owner message in relation to the ISPS code.
SAILOR 6120 mini-C SSAS is approved by Inmarsat and all major classification societies and national flag state administrators where required. In addition to its primary function as SSAS alert carrier the SAILOR 6120 mini-C SSAS can also function as a LRIT.
SAILOR 6300: MF/HF DSC CLASS A Radio
SAILOR 6300 MF/HF DSC Class A radio offers much more than just a way to meet mandatory GMDSS requirements. It is an integral part of a vessels communication system and a crucial tool when in distress and rugged, reliable, easy to use communications are a must.
SAILOR 6300 MF/HF DSC Class A radio forms part of Cobham SATCOM’s SAILOR product range.
Description
Based on the same foundation of high reliability, ease of use and leading-edge functionality that has positioned SAILOR as the leading product in maritime communications, the SAILOR 6300 MF/HF DSC Class A radio offers much more than just a way to meet mandatory GMDSS requirements. In addition to being part of the innovative SAILOR 6000 GMDSS radio series, it is an integral part of a vessels communication system and a crucial tool when in distress and rugged, reliable, easy to use communications are a must.
The SAILOR 6300 MF/HF radio provides several unique new features such as message replay functionality – a first for MF/HF radios, and the ability to connect two control units. A highly efficient power amplifier with control hardware ensures high performance and reliable communication in the marine bands from 1.6 to 30 MHz in TX mode, and ensures constant and full output power on all ITU channels.
FEATURES
⦁ SAILOR Replay – 240 seconds – First MF/HF to offer this feature
⦁ High quality graphical display – perfect night and day vision
⦁ 6W internal loudspeaker for excellent sound quality
⦁ Improved, intuitive and easy to operate menu structure
⦁ Unique, next generation radiotelex software
⦁ Multiple control units
⦁ 150W-250W-500W versions
⦁ ThraneLINK
Beam Oceana 800: Satellite Voice & Data Terminal
Beam Oceana 800: Satellite Voice & Data Terminal is an all-in-one IP54 rated terminal, a cost-effective solution on board a ship or vessel for crew and captain calling, data, tracking and instant message capabilities.
Description
Featuring an intelligent RJ11/POTS interface it enables connection of up to 5 standard corded/cordless phones or integration to a PABX system. It can support cable runs of up to 600m (2000 feet) with in-built intelligence to support standard ring, busy and dial tones.
Beam Oceana 800: Satellite Voice & Data Terminal has an integrated GPS engine providing satellite tracking and instant message reporting via SMS or email. The tracking and instant message functionality can be configured to support automated periodic polling or instant message reporting with a single button press.
Beam Oceana 800: Satellite Voice & Data Terminal has an intuitive color LCD display that provides easy and convenient access to send and receive SMS or to retrieve phone numbers stored in the terminal.
Other key features of Beam Oceana 800: Satellite Voice & Data Terminal include: a secondary SIM socket to override the internal SIM, an active privacy handset, in-built handsfree speakerphone, integrated bluetooth, USB data, desk or wall mountable.
Beam Oceana 800: Satellite Voice & Data Terminal is designed to operate with the Inmarsat FleetPhone service and is supplied with a dedicated active marine grade antenna system to provide a completely integrated solution that is ready for use anytime.
Design:
⦁ High quality IP54 rated maritime enclosure
⦁ Colour LCD screen
⦁ Compact all-in-one design
⦁ Wall or desk mounting options
⦁ Lock bolt for securing to wall
⦁ Accessible control buttons
⦁ Integrated antenna connections
⦁ In-built Slimline active privacy handset
⦁ In-built speakerphone
⦁ Cable routing LHS/TOP/BOTTOM
⦁ Dual SIM card enclosures
Instant Message and Tracking Features:
⦁ Supports LeoTRAK-Online and other tracking applications
⦁ Dedicated internal GPS receiver
Tracking:
⦁ Periodic location messages
⦁ SMS, SMS to email
⦁ Location message sent upon button press
⦁ Ignition ON/OFF reporting
⦁ Remote location polling via SMS
Instant Message Mode:
⦁ Single button press on terminal
⦁ Instant GPS location messages
⦁ Supports external “man down” pendant or button
⦁ Remote clearing of alert via SMS
Tracking/Instant Message content includes
⦁ Message ID#
⦁ Header
⦁ Latitude/Longitude
⦁ Speed
⦁ Direction
Other Key Features:
⦁ Includes BEAM Maritime Antenna (Active) Maritime grade mast mount active antenna
⦁ Adjustable Brightness
⦁ Supported by Inmarsat’s FleetPhone service
SAILOR 6130 mini-C LRIT: Satellite Terminal
The Cobham SATCOM SAILOR 6130 mini-C LRIT is a standalone LRIT solution, enabling straightforward LRIT compliance through ease of operation and reliability. It offers the same benefits towards acceptance and compliance as the legacy system, but with a number of key enhancements.
SAILOR 6130 mini-C LRIT utilises the Inmarsat satellite network.
Description
The Cobham SATCOM SAILOR 6130 mini-C LRIT is the premier standalone LRIT solution, enabling straightforward LRIT compliance through ease of operation and reliability. It offers the same benefits towards acceptance and compliance as the legacy system, but with a number of key enhancements.
This terminal is a single, self-contained and sealed unit, housing both antenna and transceiver. This design approach has proven to be rugged and reliable regardless of vessel type and application. Long Range Identification and Tracking (LRIT) was adopted by the IMO in May 2006. By installing a standalone LRIT terminal, you can be confident that it will perform to the required standards. With simple installation, the SAILOR 6130 mini-C LRIT offers a cost-effective reliable way to achieve LRIT compliance.
SAILOR 6130 mini-C LRIT utilises the Inmarsat satellite network.
VHF126-03N
Antenna
⦁ High quality VHF antenna with N-female connector
⦁ Full 1/2 λ dipole antenna design
⦁ Full omni-directional radiation pattern
⦁ DC-grounded (DC-short)
Description
VHF126-03N antennas are made of fiberglass and/or stainless steel for high-end applications where maximum range and durability are important for example usage on oceans and large lakes. We recommend fiberglass tube antennas, which are coated with smooth polyurethane and will last for many years. Small boats may also use stainless steel whip antennas because they are rugged and can withstand lots of mechanical forces during heeling of the small vessel. Depending on conditions and weight of an antenna, you can use stainless steel accessories like the adapter tube, deck, rail or wall mount.
Sea Tel Cobham 4012 GX 3-Axis marine stabilized antenna system
- 4012 GX is a 3-Axis marine stabilized antenna system includes:
- 1M 3-Axis marine stabilized antenna system
Description
- radome
- Sea Tel 4012 GX has an integrated
control unit (ICU) - 8W Ku-Band BUC
- COBHAM SATCOM antenna SYSTEM, 4012GX-91, 8W, QUAD, 61 IN, ETHERNET M&C
Intellian V130G Ku-Band Maritime Stabilized Antenna
The Intellian v130G has superior tracking performance with its 3-axis stabilization platform, which makes it ideal for offshore vessels, commercial ships, the oil and gas industry, as well as mission-critical operations, such as surveillance or vessel monitoring where uninterrupted connectivity is a requirement.
Description
The v130G’s higher-gain RF performance design enables the antenna to operate on the fringes of the signal footprint, increasing throughput and reducing operational costs.
Features
⦁ Higher-gain performance significantly increases throughput and reduces operational costs
⦁ Superior RF Performance with higher antenna gain and x-pol isolation
⦁ Remote Management using Aptus Web.
⦁ Wi-Fi enabled ACU for local control using Aptus Mobile or PC
⦁ Save installation and maintenance time with automated diagnostics and built in Spectrum Analyzer feature
⦁ Gyro-Free Satellite Search Capability without input from a ships compass
⦁ Dual VSAT Mediator integrates two VSAT antennas to combat onboard blockage zones
⦁ Open Platform system architecture works with all leading airtime service providers
⦁ 3-Year Global Warranty backed by over 300 Intellian Service and Support centers around the world
Smallest Belowdeck Footprint
The Intellian v130G antenna controller is housed in a 19” 1U rack type case, reducing consumed rackspace by 50%. In addition to being so small, the ACU includes a build in power supply and offers a number of convenient options, such as a two line digital display, with easy navigation buttons and function keys for 100% functionality of the entire system directly from the ACU front panel.
A signature Intellian ACU feature is the front panel management port. One Ethernet and two USB ports are usefully positioned on the front panel for quick connection to a PC, or for instant firmware updates via a USB drive.
All Intellian ACUs feature Wi-Fi connectivity for wireless management and control of the antenna system via PC or Mobile.
Beam DriveDOCK Extreme: Satellite Docking Station
Beam DriveDOCK Extreme Satellite Docking Station is designed for high-quality handsfree transport installation of the Iridium Extreme satellite phone, with inbuilt echo cancelling, full-duplex technology and supports Bluetooth voice connectivity.
Beam DriveDOCK Extreme Satellite Docking Station utilises the Iridium satellite network.
Description
Beam DriveDOCK Extreme Satellite Docking Station has in-built echo cancelling and full duplex technologies to provide superior voice quality and professional hands-free or privacy calls for any vehicle.
Iridium Extreme satellite phone fits securely in the dock, which features USB and serial data connectivity, phone charging and integrated antenna, data and power connection making it possible to keep all antenna cables and power permanently connected to the DriveDOCK ready for use.
Beam DriveDOCK Extreme has an easy click to lock mechanism that can be inserted and removed with a press of a button. It is purposely built to allow you to utilise the SOS emergency button and the ear-piece jack whilst docked.
Beam DriveDOCK Extreme: Satellite Docking Station also supports the use of an optional privacy handset for added convenience or the Intelligent Privacy Handset, which replicates the full functionality of the Extreme handset in another location.
